Name: 380V 50Hz 3Ph Low Pressure Screw Air Compressor 0.3-0.8 MPa Air Compressor
Brand: Jiangsu Jufeng Machinery Manufacturing Co., LTD
SKU: JF-30A~100A
Availability: InStock

Home > products > Low Pressure Screw Air Compressor >

380V 50Hz 3Ph Low Pressure Screw Air Compressor 0.3-0.8 MPa Air Compressor

380V Low Pressure Screw Air Compressor

Low Pressure Screw Air Compressor 0.3 MPa

50Hz Low Pressure Air Compressor

Place of Origin:

China

Brand Name:

Jufeng

Certification:

CE, ISO, etc.

Model Number:

JF-30A~100A

Document:

jufeng brochure 2024.pdf

Chat Now

Product Details

Weight:

420~1350 Kg

Noise Level:

≤75 DB(A)

Voltage:

380V/50Hz/3Ph Or You Need

Pressure:

0.3 MPa To 0.8 MPa

Starting Method:

Star-delta Starting

Drive Method:

Direct Drive

Capacity:

6.4~51.5 M3/min

Power:

22-90 KW

Payment & Shipping Terms

Minimum Order Quantity

Price

Packaging Details

Wooden case

Delivery Time

3-7 work days

Payment Terms

D/A, L/C, D/P, T/T, Western Union, Western Union, MoneyGram

Supply Ability

5000 units per months

380V 50Hz 3Ph Low Pressure Screw Air Compressor 0.3-0.8 MPa Air Compressor

Get Best Price

11kw - 220kw Electric Low Pressure Screw Air Compressor 0.4 / 0.5 Mpa Pressure

Get Best Price

Low Pressure Direct Drive Electric Rotary Screw Air Compressor Air Cooled 22 - 185KW

Get Best Price

22kw - 185kw Low Pressure Screw Air Compressor 0.3 Mpa Screw Type Air Compressor

Get Best Price

86-21-56420500

Chat Now

Product Description

380V 50Hz 3Ph Low Pressure Screw Air Compressor 0.3-0..8 MPa Air Compressor

Product Description:

A low-pressure screw air compressor is a type of rotary compressor designed to deliver compressed air at lower pressures (typically 0.3–0.8 MPa / 3–8 bar), making it ideal for applications requiring gentle, stable airflow without excessive energy consumption.

380V 50Hz 3Ph Low Pressure Screw Air Compressor 0.3-0.8 MPa Air Compressor 0

Features:

Product Name: Low Pressure Rotary Screw Type Air Compressor
Warranty: 1 Year of machine
Starting Method: Star-delta Starting
Capacity: 6.4~51.5 M3/min
Weight: 420~1350 Kg
Cooling Method: Air Cooling/water cooling

Parameter:

Model	Power	Pressure	Exhaust volume	Noise	Air outlet pipe diameter	Lubricating oil volume	Dimension	Weight	Other model
JF-30AZ	22kw	0.3Mpa	6.4m³/min	72±2	G2''	56+1	190012501600	1200	Contact us

Applications:

The Low Pressure Stationary Screw Air Compressor is suitable for a wide range of applications, including pneumatic tools, painting, sandblasting, and other low pressure air demands. Its direct drive method and 380V/50Hz/3Ph voltage make it easy to operate and maintain.

Some of the applications and scenarios where the Jufeng Low Pressure Screw Air Compressor can be used include:

1. Automotive repair shops
2. Construction sites
3. Painting and sandblasting operations
4. Manufacturing facilities
5. Printing and packaging industries

With its high efficiency and low maintenance requirements, the Jufeng Low Pressure Screw Air Compressor is a cost-effective solution for your low pressure air needs.

Packing:

The Low pressure screw air compressor will be securely packed in a sturdy cardboard box.
The compressor will be wrapped in protective materials to prevent any damage during transport.
All necessary components, accessories and manuals will be included in the package.

380V 50Hz 3Ph Low Pressure Screw Air Compressor 0.3-0.8 MPa Air Compressor 2

Factory photos:

380V 50Hz 3Ph Low Pressure Screw Air Compressor 0.3-0.8 MPa Air Compressor 3

380V 50Hz 3Ph Low Pressure Screw Air Compressor 0.3-0.8 MPa Air Compressor 4
